Devang Fittings is a well-known manufacturer and supplier located in Kolkata, India, focusing on top-notch 180 Degree Long Radius Elbows and 180 Degree Short Radius Elbows. With a strong dedication to precision engineering and durability, Devang Fittings caters to a diverse array of industries both across India and internationally. Their products are designed to meet global standards, ensuring reliability and performance even under high-pressure situations. Supported by state-of-the-art manufacturing facilities and a talented workforce, Devang Fittings guarantees timely delivery, competitive pricing, and exceptional customer satisfaction with every product they provide.
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Seamless 180° Long Radius Elbow Size: 1/2″~24″
ERW / Welded / Fabricated 180° Long Radius Elbow Size: 1/2″ (15 NB) to 48″ (1200NB)
Form: 180° Long Radius Elbow
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Seamless 180° Short Radius Elbow Size: 1/2″~24″
ERW / Welded / Fabricated 180° Short Radius Elbow Size: 1/2″ (15 NB) to 48″ (1200NB)
Form: 180° Short Radius Elbow
The 180 Degree Long Radius Elbow and 180 Degree Short Radius Elbow are usually made from stainless steel, carbon steel, or alloy steel, tailored to meet client specifications. These elbows boast impressive tensile strength, good yield strength, and outstanding corrosion resistance. Their mechanical properties include high ductility, hardness, and impact strength, making them perfect for demanding applications. They are produced in accordance with international standards like ASTM and ASME, ensuring high performance and structural integrity under pressure and varying temperature conditions.
Stainless Steel 45° Long Radius Elbow : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel 45° Long Radius Elbow : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel 45° Long Radius Elbow : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel 45° Long Radius Elbow : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex 45° Long Radius Elbow : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy 45° Long Radius Elbow : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel 45° Long Radius Elbow : ASTM A420 WPL3, A420 WPL6
Stainless Steel 180° Short Radius Elbow : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel 180° Short Radius Elbow : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel 180° Short Radius Elbow : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel 180° Short Radius Elbow : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex 180° Short Radius Elbow : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy 180° Short Radius Elbow : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel 180° Short Radius Elbow : ASTM A420 WPL3, A420 WPL6
Devang Fittings is a leading supplier of 180 Deg Long Redius Elbow and 180 Deg Short Redius Elbow in Kolkata, India. We offer an extensive range of 180 Deg Long Redius Elbow and 180 Deg Short Redius Elbow, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose 180 Deg Long Redius Elbow and 180 Deg Short Redius Elbow from Devang Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
180° Long Radius and 180° Short Radius Elbows provide users with numerous benefits when it comes to industrial piping systems. Long Radius Elbows help you accomplish smooth flow with very few restrictions and significant reductions in turbulence and pressure loss, which are most effective for applications requiring quick and efficient movement of fluid or gas in your project. The unique combination of elements in the Long Radius Elbow also decreases wear and tear to the system, which extends the service life of all your piping components as well. Furthermore, Short Radius Elbows are great for installations that won’t allow you a lot of space for implementation but help you achieve significantly sharp directional changes without sacrificing any of your system’s performance with a Long Radius design option. Put them both together, and you have two highly durable materials that are impervious to corrosion, and can withstand extreme high pressures and high temperatures found in piping systems and equipment installations in a variety of industries.
Yes, custom sizes for 180 Deg Long Redius Elbow and 180 Deg Short Redius Elbow are available at Devang Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@devangfittings.co.in.
| NPS | O.D. D | 90 degrees Long Radius Center-to-End A | 45 degrees Long Radius Center-to-End B | 90 degrees 3D Center-to-End A | 45 degrees 3D Center-to-End B |
| 1/2 | 21.3 | 38 | 16 | – | – |
| 3/4 | 26.7 | 38 | 19 | 57 | 24 |
| 1 | 33.4 | 38 | 22 | 76 | 31 |
| 1 ¼ | 42.2 | 48 | 25 | 95 | 39 |
| 1 ½ | 48.3 | 57 | 29 | 114 | 47 |
| 2 | 60.3 | 76 | 35 | 152 | 63 |
| 2 ½ | 73 | 95 | 44 | 190 | 79 |
| 3 | 88.9 | 114 | 51 | 229 | 95 |
| 3 ½ | 101.6 | 133 | 57 | 267 | 111 |
| 4 | 114.3 | 152 | 64 | 305 | 127 |
| 5 | 141.3 | 190 | 79 | 381 | 157 |
| 6 | 168.3 | 229 | 95 | 457 | 189 |
| 8 | 219.1 | 305 | 127 | 610 | 252 |
| 10 | 273 | 381 | 159 | 762 | 316 |
| 12 | 323.8 | 457 | 190 | 914 | 378 |
| 14 | 355.6 | 533 | 222 | 1067 | 441 |
| 16 | 406.4 | 610 | 254 | 1219 | 505 |
| 18 | 457 | 686 | 286 | 1372 | 568 |
| 20 | 508 | 762 | 318 | 1524 | 632 |
| 22 | 559 | 838 | 343 | 1676 | 694 |
| 24 | 610 | 914 | 381 | 1829 | 757 |
| 26 | 660 | 991 | 406 | 1981 | 821 |
| 28 | 711 | 1067 | 438 | 2134 | 883 |
| 30 | 762 | 1143 | 470 | 2286 | 964 |
| 32 | 813 | 1219 | 502 | 2438 | 1010 |
| 34 | 864 | 1295 | 533 | 2591 | 1073 |
| 36 | 914 | 1372 | 565 | 2743 | 1135 |
| 38 | 965 | 1448 | 600 | 2896 | 1200 |
| 40 | 1016 | 1524 | 632 | 3048 | 1264 |
| 42 | 1067 | 1600 | 660 | 3200 | 1326 |
| 44 | 1118 | 1676 | 695 | 3353 | 1389 |
| 46 | 1168 | 1753 | 727 | 3505 | 1453 |
| 48 | 1219 | 1829 | 759 | 3658 | 1516 |
These elbows find extensive use in industries where fluids or gases need to change direction at a 180-degree angle without creating turbulence or pressure loss. Common applications include petrochemical plants, oil and gas pipelines, power generation, shipbuilding, and water treatment facilities. Long radius elbows are favored for smoother flow and reduced resistance, while short radius elbows are ideal for compact, high-pressure systems. Their sturdy construction and resistance to corrosion and wear make them suitable for both aboveground and underground installations, ensuring long-term operational efficiency and reliability.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
