Devang Fittings is a well-respected manufacturer and supplier located in Kolkata, India, known for its top-notch 45-degree long radius and short radius elbows. The company prides itself on precision and durability, ensuring that its products meet both national and international standards. Crafted from high-quality raw materials and utilizing cutting-edge manufacturing techniques, these elbows are designed to perform exceptionally well in a variety of industrial applications. With a reputation for timely deliveries, competitive pricing, and a strong focus on customer service, Devang Fittings has built a solid trust among clients in sectors like oil and gas, chemical processing, and power generation.
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Seamless 45° Long Radius Elbow Size: 1/2″~24″
ERW / Welded / Fabricated 45° Long Radius Elbow Size: 1/2″ (15 NB) to 48″ (1200NB)
Form: 45° Long Radius Elbow
The 45-degree long radius and short radius elbows from Devang Fittings are typically made from stainless steel, carbon steel, and alloy steel. These materials provide outstanding strength, corrosion resistance, and durability. They boast impressive mechanical properties, including high tensile strength (ranging from 415 to 860 MPa), good yield strength, and superior hardness, making them perfect for high-pressure and high-temperature environments. These elbows maintain their structural integrity and perform reliably even under demanding conditions, adhering to international standards such as ASTM and ASME.
Stainless Steel 45° Long Radius Elbow : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel 45° Long Radius Elbow : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel 45° Long Radius Elbow : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel 45° Long Radius Elbow : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex 45° Long Radius Elbow : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy 45° Long Radius Elbow : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel 45° Long Radius Elbow : ASTM A420 WPL3, A420 WPL6
Devang Fittings is a leading supplier of 45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow in Kolkata, India. We offer an extensive range of 45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose 45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow from Devang Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
45° Long Radius and 45° Short Radius Elbows offer distinct advantages depending on application needs. The Long Radius Elbow provides a gradual, smooth bend, ensuring minimal pressure loss and efficient flow, making it ideal for high-velocity systems. It is commonly used in larger piping setups. The Short Radius Elbow, on the other hand, is perfect for compact installations with limited space, offering quick directional changes. Both types are highly durable, corrosion-resistant, and made from strong materials like stainless steel, ensuring long-lasting performance in industries such as oil and gas, HVAC, and chemical processing.
Yes, custom sizes for 45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow are available at Devang Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@devangfittings.co.in.
| NPS | O.D. D | 90 degrees Long Radius Center-to-End A | 45 degrees Long Radius Center-to-End B | 90 degrees 3D Center-to-End A | 45 degrees 3D Center-to-End B |
| 1/2 | 21.3 | 38 | 16 | – | – |
| 3/4 | 26.7 | 38 | 19 | 57 | 24 |
| 1 | 33.4 | 38 | 22 | 76 | 31 |
| 1 ¼ | 42.2 | 48 | 25 | 95 | 39 |
| 1 ½ | 48.3 | 57 | 29 | 114 | 47 |
| 2 | 60.3 | 76 | 35 | 152 | 63 |
| 2 ½ | 73 | 95 | 44 | 190 | 79 |
| 3 | 88.9 | 114 | 51 | 229 | 95 |
| 3 ½ | 101.6 | 133 | 57 | 267 | 111 |
| 4 | 114.3 | 152 | 64 | 305 | 127 |
| 5 | 141.3 | 190 | 79 | 381 | 157 |
| 6 | 168.3 | 229 | 95 | 457 | 189 |
| 8 | 219.1 | 305 | 127 | 610 | 252 |
| 10 | 273 | 381 | 159 | 762 | 316 |
| 12 | 323.8 | 457 | 190 | 914 | 378 |
| 14 | 355.6 | 533 | 222 | 1067 | 441 |
| 16 | 406.4 | 610 | 254 | 1219 | 505 |
| 18 | 457 | 686 | 286 | 1372 | 568 |
| 20 | 508 | 762 | 318 | 1524 | 632 |
| 22 | 559 | 838 | 343 | 1676 | 694 |
| 24 | 610 | 914 | 381 | 1829 | 757 |
| 26 | 660 | 991 | 406 | 1981 | 821 |
| 28 | 711 | 1067 | 438 | 2134 | 883 |
| 30 | 762 | 1143 | 470 | 2286 | 964 |
| 32 | 813 | 1219 | 502 | 2438 | 1010 |
| 34 | 864 | 1295 | 533 | 2591 | 1073 |
| 36 | 914 | 1372 | 565 | 2743 | 1135 |
| 38 | 965 | 1448 | 600 | 2896 | 1200 |
| 40 | 1016 | 1524 | 632 | 3048 | 1264 |
| 42 | 1067 | 1600 | 660 | 3200 | 1326 |
| 44 | 1118 | 1676 | 695 | 3353 | 1389 |
| 46 | 1168 | 1753 | 727 | 3505 | 1453 |
| 48 | 1219 | 1829 | 759 | 3658 | 1516 |
These 45-degree elbows are crucial components in piping systems where a smooth and efficient change in fluid direction is necessary. The long radius elbows are particularly suited for applications that require low-pressure drops and smooth flow, making them a common choice in petrochemical, power, and water treatment plants. On the other hand, short radius elbows, with their compact design, are ideal for tight spaces where high flow velocity is essential, such as in shipbuilding and compact machinery. Both types play a vital role in maintaining flow efficiency and minimizing turbulence in pipelines across various industrial and commercial sectors.
