Devang Fittings, located in Kolkata, India, has built a solid reputation as a reliable manufacturer and supplier of high-performance piping components. They specialize in precision-engineered 90° Short Radius Elbows, perfect for tight-fit and compact piping layouts. These elbows are crafted in accordance with ASME B16.9 and ANSI standards, making them an excellent choice for redirecting flow in confined spaces. Available in carbon steel, stainless steel, and alloy steel grades, their short radius elbows are designed to deliver exceptional strength and dependable pressure handling. Devang Fittings caters to various industries, including oil & gas, chemical processing, shipbuilding, and power generation, ensuring that their products meet strict dimensional accuracy and durability requirements for critical piping systems.
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Seamless Pipe 90° Short Radius Elbow Size: 1/2″~24″
ERW / Welded / Fabricated 90° Short Radius Elbow Size: 1/2″ (15 NB) to 48″ (1200NB)
Form: 90° Short Radius Elbow
Typically, 90° Short Radius Elbows are made from materials such as carbon steel (A234 WPB), stainless steel (304/316), and various alloy steels. These materials include key elements like carbon, manganese, chromium, and nickel, which contribute to their impressive strength, corrosion resistance, and stability under temperature changes. Common mechanical properties feature a tensile strength ranging from 450 to 620 MPa, yield strength between 240 and 450 MPa, and an elongation of 20 to 30%. Thanks to their short center-to-end distance, these elbows facilitate sharp directional changes in pipelines while maintaining their mechanical integrity even under moderate to high-pressure and thermal stress conditions.
Stainless Steel 90° Short Radius Elbow : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel 90° Short Radius Elbow : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel 90° Short Radius Elbow : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel 90° Short Radius Elbow : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex 90° Short Radius Elbow : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy 90° Short Radius Elbow : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel 90° Short Radius Elbow : ASTM A420 WPL3, A420 WPL6
Devang Fittings is a leading supplier of 90 Deg Short Redius Elbow in Kolkata, India. We offer an extensive range of 90 Deg Short Redius Elbow, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose 90 Deg Short Redius Elbow from Devang Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
90° Short Radius Elbows are widely utilized in compact piping systems where space is at a premium and sharp directional changes are necessary. They are particularly well-suited for environments like boiler rooms, ship engine rooms, chemical reactors, and skid-mounted systems. In the oil & gas, petrochemical, and refinery sectors, these elbows help manage flow redirection while reducing the need for extra fittings. Their tight turning radius conserves piping space but may lead to increased pressure loss, making them ideal for low to moderate velocity systems. These elbows play a crucial role in settings where efficient flow management is essential.
Yes, custom sizes for 90 Deg Short Redius Elbow are available at Devang Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@devangfittings.co.in.
| NPS | O.D. D | Center-to-End A |
| 1 | 33.4 | 25 |
| 1 ¼ | 42.2 | 32 |
| 1½ | 48.3 | 38 |
| 2 | 60.3 | 51 |
| 2 ½ | 73 | 64 |
| 3 | 88.9 | 76 |
| 3 ½ | 101.6 | 89 |
| 4 | 114.3 | 102 |
| 5 | 141.3 | 127 |
| 6 | 168.3 | 152 |
| 8 | 219.1 | 203 |
| 10 | 273 | 254 |
| 12 | 323.8 | 305 |
| 14 | 355.6 | 356 |
| 16 | 406.4 | 406 |
| 18 | 457 | 457 |
| 20 | 508 | 508 |
| 22 | 559 | 559 |
| 24 | 610 | 610 |
90° Short Radius Elbows are commonly used in compact piping systems where space is limited. These elbows are ideal for applications in industries such as HVAC, plumbing, and chemical processing, where quick directional changes are needed within confined areas. They are also utilized in smaller-scale industrial setups, fuel lines, and water distribution systems. While providing efficient flow control, they help maintain optimal system performance in tight spaces, offering durability and resistance to corrosion, high pressures, and temperatures in various operational conditions.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
