Devang Fittings is a leading manufacturer and supplier of Alloy Steel WP9 Buttweld Fittings from Kolkata, India. We are specialized in the production of high-quality elbows, tees, reducers, and caps that conform to ASTM A234 specifications for safe operation of high-pressure and high-temperature piping systems. Our WP9 buttweld fittings possess superior mechanical strength, corrosion resistance, and dimensional tolerance. Supplying heavy-duty industries like oil and gas, petrochemical, power generation, and refineries, Devang Fittings provides reliable and leakage-free fittings which meet the challenging working conditions and offer long-lasting safety and efficiency.
| Specifications | : | ASTM A234 / ASME SA234 |
| Size | : | 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated) |
| Standards | : | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Thickness | : | Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS |
| Type | : | Seamless / Welded / Fabricated |
WP9 is a chromium-molybdenum alloy steel having about 2.25% chromium and 1% molybdenum in its composition. Its resistance to high-temperature oxidation, creep, and corrosion is improved. WP9 fittings usually have tensile strength of approximately 585 MPa, yield strength of approximately 310 MPa, and elongation of approximately 22–25%. The fittings are mechanically stable and resistant to toughness against heat and corrosive stresses and are hence best used for steam line applications, pressure vessels, and high-temperature process piping applications. The fittings are heat-treated for maximum performance and durability.
| Grade | C | Mn | Si | S | P | Cr | Mo |
| A234 WP9 | ≤0.15 | ≤0.6 | 1.00 | ≤0.03 | ≤0.03 | 8-10 | 0.99-1.10 |
| Grade | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation % |
| A234 WP9 | 380 min | 585 min | ≥30 |
Devang Fittings one of the largest suppliers of Alloy Steel WP9 Buttweld Fittings in Kolkata, India. We specialize in providing a wide range of high-quality, durable fittings for various industrial applications. Our inventory includes elbows, tees, reducers, couplings, and other essential fittings designed to offer exceptional corrosion resistance and strength. Alloy Steel WP9 is known for its cost-effectiveness and excellent mechanical properties, making it ideal for industries such as construction, chemical processing, and food processing. With a commitment to customer satisfaction, timely delivery, and competitive pricing, we are the trusted choice for Alloy Steel WP9 Buttweld Fittings in the India.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Alloy Steel WP9 Buttweld Fittings from Devang Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
| NPS (Normal Pipe Size) | O.D. (Outside Daimeter) | Elbow 90 Deg | Elbow 45 Deg | Return Elbow 180 Deg | ||||
| (inch) | Long Radius Elbow | Short Radius | Long Radius Elbow | Long Radius Elbow | ||||
| (millimeter/ MM) | (inch./ Inches) | Center to Face (Inches) | Center to Face (Inches) | Center to Face (Inches) | Radius (Inches) | Center to Center (Inches) | Back to face (Inches) | |
| 1/2 | 21.3 | 0.840 | 1 1/2 | – | 5/8 | 2 | 1 7/8 | |
| 3/4 | 26.7 | 1.050 | 1 1/8 | – | 7/16 | 2 1/4 | 1 11/16 | |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 | 7/8 | 3 | 2 3/16 | |
| 1 1/4 | 42.2 | 1.660 | 1 7/8 | 1 1/4 | 1 | 3 3/4 | 2 3/4 | |
| 1 1/2 | 48.3 | 1.900 | 2 1/4 | 1 1/2 | 1 1/8 | 3 | 4 1/2 | 3 1/4 |
| 2 | 60.3 | 2.375 | 3 | 2 | 1 3/8 | 4 | 6 | 4 3/16 |
| 2 1/2 | 73.0 | 2.875 | 3 3/4 | 2 1/2 | 1 3/4 | 5 | 7 1/2 | 5 3/16 |
| 3 | 88.9 | 3.500 | 4 1/2 | 3 | 2 | 6 | 9 | 6 1/4 |
| 3 1/2 | 101.6 | 4.000 | 5 1/4 | 3 1/2 | 2 1/4 | 7 | 10 1/2 | 7 1/4 |
| 4 | 114.3 | 4.500 | 6 | 4 | 2 1/2 | 8 | 12 | 8 1/4 |
| 5 | 141.3 | 5.563 | 7 1/2 | 5 | 3 1/8 | 10 | 15 | 10 5/16 |
| 6 | 168.3 | 6.625 | 9 | 6 | 3 3/4 | 12 | 18 | 12 5/16 |
| 8 | 219.1 | 8.625 | 12 | 8 | 5 | 12 | 24 | 16 5/16 |
| 10 | 273.1 | 10.750 | 15 | 10 | 6 1/4 | 15 | 30 | 20 3/8 |
| 12 | 323.9 | 12.750 | 18 | 12 | 7 1/2 | 18 | 36 | 24 3/8 |
Alloy Steel WP9 Buttweld Fittings offer several advantages, making them ideal for high-temperature and high-pressure applications. Their composition, featuring chromium and molybdenum, enhances their resistance to oxidation, corrosion, and wear, ensuring long-lasting performance. WP9 Fittings are highly durable, with excellent strength and weldability, making them suitable for demanding industries such as power generation, petrochemical, and oil & gas. They provide superior resistance to thermal fatigue and carburization, ensuring the integrity of piping systems under extreme conditions. Additionally, they offer ease of installation and minimal maintenance over time.
| Pressure-Temperature ratings for ASME B16.9 ASTM A234 WP9 Pipe Fittings(psig) | |||||
| Temperature Ratings | Pressure Class | ||||
| 150 | 300 | ||||
| 1/4 – 1 Inches | 1 1/4 – 2 Inches | 2 1/2 – 3 Inches | |||
| (oF) | (oC) | ||||
| -20 to 150 | -29 to 66 | 300 | 2000 | 1500 | 1000 |
| 200 | 93 | 265 | 1785 | 1350 | 910 |
| 250 | 121 | 225 | 1575 | 1200 | 825 |
| 300 | 149 | 185 | 1360 | 1050 | 735 |
| 350 | 177 | 150 | 1150 | 900 | 650 |
| 400 | 204 | – | 935 | 750 | 560 |
| 450 | 232 | – | 725 | 600 | 475 |
| 500 | 260 | – | 510 | 450 | 385 |
| 550 | 288 | – | 300 | 300 | 300 |
Yes, custom sizes are available for Alloy Steel WP9 Buttweld Fittings to meet specific requirements. We offer tailored solutions to ensure precise fit and performance for various applications. For more information, please contact us at sales@devangfittings.co.in.
Alloy Steel WP9 Buttweld Fittings find extensive application in power generation plants, oil refineries, chemical processing plants, and petrochemical facilities. They are suited for high-temperature steam piping, boilers, heat exchangers, and reactor systems where resistance against scaling, oxidation, and creep is demanded. These fittings ensure safe and stable flow control in hostile environments and provide trouble-free operations. Their strong build and corrosion resistance lower maintenance intervals and downtime, positioning them as a favorite for mission-critical industrial processes requiring high temperature and pressure levels.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
