Carbon Steel Forged Fittings

Devang Fittings is a well-respected manufacturer and supplier of Carbon Steel Forged Fittings based in Kolkata, India. We pride ourselves on delivering strong and high-performance piping components tailored for industrial systems. Our forged fittings are crafted from top-notch carbon steel and come in a variety of types, including elbows, tees, couplings, unions, and plugs. Built to endure high pressure and temperature, these fittings guarantee secure, leak-proof connections. Meeting ASME, ASTM, and ANSI standards, our carbon steel forged fittings are widely utilized in sectors like oil & gas, petrochemical, power generation, and water treatment, thanks to their exceptional strength and long-lasting reliability.

Carbon Steel High Pressure Forged Fittings India, Carbon Steel Threaded Fittings United kingdom, Carbon Forged Fittings Kolkata, Carbon Steel Socket weld Fittings Kolkata, CS Forged Fittings India, Carbon Steel A105 Forged Fittings Kolkata, Carbon Steel Socket weld Fittings India, Carbon Steel ASTM A105 Threaded Fittings Manufacturer in Kolkata, India.

Carbon Steel Forged Fittings Specification

Forged Fittings Specifications	ASTM A105/ ASME SA105
Carbon Steel Forged Fittings size	1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Carbon Steel Forged Fittings Dimensions	ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Carbon Steel Forged Fittings Types	Socketweld Fittings, Screwed-Threaded Fittings
ASTM A105 Carbon Steel Forged Fittings Pressure Rating	Threaded End-2000lb/ 3000lb/ 6000lbs Socket-weld End-3000/ 6000/ 9000lbs
Carbon Steel Forged Fittings Thread	NPT, BSPT, BSPP
Carbon Steel Forged Fittings Test Certificates	EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc
Carbon Forged Fittings Origin & Mills	Japanese, Indian, USA, Korean, European, Ukraine, Russian
Specialized manufacturer of	90º Elbows, 45º Elbows, Tees, Cross, Couplings, Reducers, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows, Plugs

Carbon Steel Forged Fittings are generally made from A105 grade carbon steel, which consists of carbon (≤0.35%), manganese (0.6–1.05%), phosphorus (≤0.035%), sulfur (≤0.04%), and silicon (0.1–0.35%). These fittings boast impressive mechanical strength, with a tensile strength of ≥ 485 MPa, yield strength of ≥ 250 MPa, and elongation of ≥ 22%. Their remarkable toughness and ductility make them suitable for both cryogenic and high-temperature applications. The forged design enhances grain uniformity, fatigue resistance, and durability, making them ideal for demanding industrial environments.

Manufacturing Standards of Carbon Steel Forged Fittings

ASTM A105 / A105M	Forged Fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic Carbon Steel Forged Fittings
BS21	Threading.
BS3799	Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry
ANSI B16.11	Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings
ANSI/ASME B1.20.1	Pipe threads, general purpose (inch).
ISO 4144	Carbon Steel fittings threaded to ISO 7-1.
MSS SP-95	Swage(d) Nipples and Bull Plugs

Ready Stock of Carbon Steel A105 Forged Elbow India, CS Forged Cross Trader United kingdom, Carbon Steel Coupling Kolkata, Competitive Price of Carbon Steel Forged Tees Kolkata, Largest Stockholder of Carbon Forged Fittings in India, ASTM A105 Socket weld Fittings Manufacturers in Kolkata, Carbon Steel Forged Fittings India.

ANSI B16.11 Carbon Steel Forged Fittings Forms & Availability

Products		Size
ASTM A105 Carbon Steel 90° Elbow	ASTM A105 Carbon Steel 45° Elbow	Sizes 1/8″– 4″ Pressure Ratings – 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
ASTM A105 Carbon Steel Forged Tee	ASTM A105 Carbon Steel Union
ASTM A105 Carbon Steel Forged Cross	ASTM A105 Carbon Steel Insert
ASTM A105 Carbon Steel Screwed Bushing	ASTM A105 Carbon Steel Threaded Pipe Nipple
ASTM A105 Carbon Steel Forged Socket weld Cap	ASTM A105 Carbon Steel Screwed Coupling
ASTM A105 Carbon Steel Forged Plug	ASTM A105 Carbon Steel Street Elbow

Carbon Steel Forged Fittings Standard

Standard Code	Standard Name
ANSI ASME SA-105	Forged fittings
ANSI ASME B16.11	Socket-welding and Threaded forged fittings
MSS SP-79	Socket-welding reducing Inserts
MSS SP-83	Class 3000 steel socket-welding and threaded unions
MSS SP-95	Swaged nipples and round plugs
MSS SP-97	SW,TH and BW ends for integrally reinforced forged branch outlet

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Carbon Steel Forged Fittings play a crucial role in high-pressure piping systems across various industries, including oil & gas, chemical processing, power plants, refineries, and shipbuilding. These fittings are essential for connecting, controlling, and redirecting the flow of gases, steam, or liquids under extreme pressure and temperature conditions. Thanks to their superior strength, leak resistance, and weldability, they are perfect for boiler lines, hydraulic systems, and high-load mechanical structures. Additionally, carbon steel forged fittings provide a long service life even in corrosive and abrasive environments, making them a top choice for many applications.

Why Choose Carbon Steel Forged Fittings from Devang Fittings?

Carbon Steel Forged Fittings from Devang Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

Buy Carbon Steel Full Coupling India, ASME SA105 Forged Bushing United kingdom, ANSI B16.11 CS Forged Plugs Kolkata, Carbon Forged Cap Kolkata, CS ASTM A105 Forged Socket weld Fittings Stockist India, Carbon Steel Threaded Fittings Dealer Kolkata, Carbon Steel Threaded Nipple Wholesaler India, Carbon Half Coupling India, Carbon Steel Forged Union United kingdom, Carbon Steel Welding Boss Kolkata, Carbon Steel Industrial Forged Fittings Supplier in Midlnad, India.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Types of Carbon Steel Forged Fittings

Are Custom Sizes Available for Carbon Steel Forged Fittings?

Yes, custom sizes for Carbon Steel Forged Fitting are available at Devang Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@devangfittings.co.in.

Ready Stock of Carbon Steel A105 Forged Elbow India, CS Forged Cross Trader United kingdom, Carbon Steel Coupling Kolkata, Competitive Price of Carbon Steel Forged Tees Kolkata, Largest Stockholder of Carbon Forged Fittings in India, ASTM A105 Socket weld Fittings Manufacturers in Kolkata, Carbon Steel Forged Fittings India.

Application Industry of Carbon Steel Forged Fittings

Carbon steel forged fittings are widely used in industries such as oil and gas, petrochemical, power generation, and construction. They are essential for creating strong, leak-free connections in high-pressure pipelines, valves, and machinery. Common applications include HVAC systems, water treatment plants, refineries, and fire protection systems. Their durability and resistance to wear, corrosion, and high temperatures make them ideal for harsh environments, ensuring reliable performance in critical systems where safety and performance are paramount. These fittings are also used in transportation and marine industries.
