Devang Fittings is a reputable manufacturer and supplier located in Kolkata, India, that specializes in top-notch Duplex Steel UNS S32205 Forged Fittings. With a strong dedication to quality and precision, the company offers a diverse selection of forged fittings that are celebrated for their strength, durability, and resistance to corrosion. These fittings are crafted using cutting-edge techniques and rigorous quality control measures, ensuring they meet global standards. Devang Fittings serves a variety of industrial sectors, providing tailored solutions to fulfill specific client needs while keeping prices competitive and ensuring timely delivery both domestically and internationally.
| Size | : | 1/2″NB TO 4″NB IN |
| Standard | : | ASTM A182 / ASME SA182 |
| Dimensions | : | ANSI/ASME B16.11 & BS3799, etc. |
| Grade | : | UNS S31803, S32205, S2205, S32550, S32750, S32760. |
| Class | : | 2000LBS, 3000LBS, 6000LBS, 9000LBS, etc. |
Duplex Steel UNS S32205 Forged Fittings boast a well-balanced chemical makeup of about 22% chromium, 5–6% nickel, 3% molybdenum, and nitrogen, which grants them outstanding resistance to corrosion and pitting. Their mechanical properties include impressive tensile strength around 620 MPa, yield strength of 450 MPa, and good elongation (at least 25%). These fittings also demonstrate remarkable toughness and fatigue strength. The duplex microstructure guarantees exceptional performance in challenging environments, making them perfect for demanding applications in both low and high temperatures.
| UNS S31803 | Ni | Cr | Mo | Mn | Si | C | N | S | P | Fe |
| min | 4.5 | 22.0 | 3.0 | – | – | – | 0.14 | – | – | – |
| max | 6.5 | 23.0 | 3.5 | 2.0 | 1.0 | 0.03 | 0.2 | 0.02 | 0.03 | Balance |
| Grade | S31803 |
| Density (g/cm 3) | 7.805 |
| Density (lb/in 3) | 0.285 |
| Melting Point (°C) | 1420 – 1465 |
| Melting Point (°F) | 2588 – 2669; |
Devang Fittings is a leading supplier of Duplex Steel UNS S32205 Forged Fittings in Kolkata, India. We offer an extensive range of Duplex Steel UNS S32205 Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Duplex Steel UNS S32205 Forged Fittings from Devang Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Duplex Steel UNS S32205 Forged Fittings offer numerous advantages, including superior corrosion resistance, particularly in chloride environments, making them ideal for marine, chemical, and oil and gas industries. Their unique duplex microstructure combines the best of both austenitic and ferritic steels, providing high strength and excellent resistance to stress corrosion cracking. These fittings also offer enhanced fatigue resistance, high toughness, and excellent weldability, ensuring reliability and ease of installation. With impressive mechanical properties, Duplex Steel UNS S32205 Forged Fittings are perfect for high-pressure, high-temperature applications, delivering long-term durability and performance.
Yes, custom sizes for Duplex Steel UNS S32205 Forged Fittings are available at Devang Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@devangfittings.co.in.
| STANDARD | UNS | |
| Duplex Steel Forged Fittings | S31803 / S32205 |
| DN-NPT | MAJOR DIAMETER MM | TAPPING /DRILL SIZE MM | TPI | PITCH MM |
|---|---|---|---|---|
| 1/16″ | 7.895 | 6.00 | 27 | 0.941 |
| 1/8″ | 10.242 | 8.25 | 27 | 0.941 |
| 1/4″ | 13.616 | 10.70 | 18 | 1.411 |
| 3/8″ | 17.055 | 14.10 | 18 | 1.411 |
| 1/2″ | 21.223 | 17.40 | 14 | 1.814 |
| 3/4″ | 26.568 | 22.60 | 14 | 1.814 |
| 1″ | 33.228 | 28.50 | 11.5 | 2.209 |
| 1¼” | 41.985 | 37.00 | 11.5 | 2.209 |
| 1½” | 48.054 | 43.50 | 11.5 | 2.209 |
| 2″ | 60.092 | 55.00 | 11.5 | 2.209 |
| 2½” | 72.699 | 65.50 | 8 | 3.175 |
| 3″ | 88.608 | 81.50 | 8 | 3.175 |
| 3½” | 101.316 | 94.30 | 8 | 3.175 |
| 4″ | 113.973 | 107.00 | 8 | 3.175 |
| 5″ | 141.300 | 134.384 | 8 | 3.175 |
| 6″ | 168.275 | 161.191 | 8 | 3.175 |
| 8″ | 219.075 | 211.673 | 8 | 3.175 |
| 10″ | 273.050 | 265.311 | 8 | 3.175 |
| 12″ | 323.850 | 315.793 | 8 | 3.175 |
| Description | Class Designation | ||
|---|---|---|---|
| 3000 | 6000 | 9000 | |
| Elbows 45 and 90 degrees, Tees, Crosses, Couplings, Half-Couplings, End or Pipe Caps | 1/2 – 4 | 1/2 – 2 | 1/2 – 2 |
| 1/2 – 4 | 1/2 – 2 | 1/2 – 2 | |
| 1/2 – 4 | 1/2 – 2 | 1/2 – 2 | |
| Pipe Size by Wall Thickness | SCH 80 / XS | SCH 160 | XXS |
These Duplex Steel UNS S32205 Forged Fittings find extensive use in industries like oil and gas, petrochemicals, marine, chemical processing, and power generation. Their excellent resistance to chloride-induced stress corrosion cracking and general corrosion makes them ideal for offshore platforms, heat exchangers, pressure vessels, and desalination plants. Moreover, their high mechanical strength allows for lighter structural components. These fittings are also utilized in fire-fighting systems, pipelines, and water treatment facilities, where durability and corrosion resistance are essential for long-lasting performance.
