Devang Fittings is a well-known manufacturer and supplier of premium quality piping solutions, located in Kolkata. India. Our range of Incoloy 800, 800H and 800HT Buttweld Fittings are known for their incredible strength, corrosion resistance and ability to withstand extreme temperatures. Devang Fittings is your source for all your Incoloy fittings instrument with performance in mind. These high-performing fittings are for demanding applications in industries like chemical processing, power generation, petrochemicals and more! Devang Fittings is committed to providing precisely engineered piping solutions and ensuring customer satisfaction by providing components and solutions to your exact specifications.
Specifications : ASTM B366 / ASME SB366
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Size : Seamless Butt Weld Fittings: 1/2″ – 10″, Welded Butt Weld Fittings: 1/2″ – 48″
Type : Seamless / Welded / Fabricated
Schedule : Sch 5 TO Sch XXS.
Thickness : 20 Swg., 18 Swg., 16 Swg., 14 Swg., 12 Swg., 10 Swg., & Sch. 10, Sch. 40, Sch. 80 etc
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| 800 | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60ᴬ | 0.15 – 0.60ᴬ |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
Incoloy 800, 800H, and 800HT are well known for their excellent high-temperature strength, oxidation resistance, and good weldability. Both Incoloy 800 and its counterparts contain approximately 30% nickel and 20% chromium, and they also contain minor additions of titanium (notably for 800H and 800HT) designed to improve creep and rupture strength. Incoloy 800 buttweld fittings are designed to be resistant to scaling and carburization in high temperature environments, which make them suitable for a variety of high temperature applications including chemical processing, power generation, and applications such as heat exchangers or cyclones. When you consider the mechanical properties, you will see high tensile strength, good ductility along with good corrosion and stress corrosion resistance for the alloy. Incoloy 800, along with 800H and 800HT retain stability at elevated temperatures.
Devang Fittings is a leading supplier of Incoloy 800/ 800H/ 800HT Buttweld Fittings in Kolkata, India. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Incoloy 800/ 800H/ 800HT Buttweld Fittings from Devang Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Incoloy 800, 800H, and 800HT buttweld fittings have many benefits to offer. They all have excellent high-temperature strength properties and exceptional oxidation and carburization resistance. Incoloy 800, 800H, and 800HT provide stability and structural integrity even after sustained exposure to extreme environments, making them ideal for use in chemical processing, power generation, and heat exchangers. Titanium is added to 800H and 800HT for improved creep resistance, and where long-term performance in high temperature applications is critical. Incoloy 800, 800H, and 800HT excellent weldability makes them easy to fabricate into complex shapes, and their high resistance to localized corrosion and stress cracking help ensure longevity. Alloys 800, 800H and 800HT provide durability and stability while reducing maintenance and downtime for high temperature industrial applications.
| Nominal PipeSize | Outside Diameter | 90° Elbows | 45° Elbows | 180° Returns | ||||
|---|---|---|---|---|---|---|---|---|
| (inches) | – | Long Radius | Short Radius | Long Radius | Long Radius | |||
| (mm) | (inches) | Center to Face (inches) | Center to Face (inches) | Center to Face (inches) | Radius (inches) | Center to Center (inches) | Back to face (inches) | |
| 1/2 | 21.3 | 0.840 | 1 1/2 | – | 5/8 | 2 | 1 7/8 | |
| 3/4 | 26.7 | 1.050 | 1 1/8 | 7/16 | 2 1/4 | 1 11/16 | ||
| 1 | 33.4 | 1.315 | 1 1/2 | 1 | 7/8 | 3 | 2 3/16 | |
| 1 1/4 | 42.2 | 1.660 | 1 7/8 | 1 1/4 | 1 | 3 3/4 | 2 3/4 | |
| 1 1/2 | 48.3 | 1.900 | 2 1/4 | 1 1/2 | 1 1/8 | 3 | 4 1/2 | 3 1/4 |
| 2 | 60.3 | 2.375 | 3 | 2 | 1 3/8 | 4 | 6 | 4 3/16 |
| 2 1/2 | 73.0 | 2.875 | 3 3/4 | 2 1/2 | 1 3/4 | 5 | 7 1/2 | 5 3/16 |
| 3 | 88.9 | 3.500 | 4 1/2 | 3 | 2 | 6 | 9 | 6 1/4 |
| 3 1/2 | 101.6 | 4.000 | 5 1/4 | 3 1/2 | 2 1/4 | 7 | 10 1/2 | 7 1/4 |
| 4 | 114.3 | 4.500 | 6 | 4 | 2 1/2 | 8 | 12 | 8 1/4 |
| 5 | 141.3 | 5.563 | 7 1/2 | 5 | 3 1/8 | 10 | 15 | 10 5/16 |
| 6 | 168.3 | 6.625 | 9 | 6 | 3 3/4 | 12 | 18 | 12 5/16 |
| 8 | 219.1 | 8.625 | 12 | 8 | 5 | 12 | 24 | 16 5/16 |
| 10 | 273.1 | 10.750 | 15 | 10 | 6 1/4 | 15 | 30 | 20 3/8 |
| 12 | 323.9 | 12.750 | 18 | 12 | 7 1/2 | 18 | 36 | 24 3/8 |
Yes, custom sizes for Incoloy 800/ 800H/ 800HT Buttweld Fittings are available at Devang Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@devangfittings.co.in.
Incoloy 800, 800H and 800HT Buttweld fittings are utilized frequently in high-temperature and corrosive environments. The properties of these alloys are found in the chemical industry, petrochemical industry, and power generation industry in applications like heat exchangers, boiler applications, and piping systems. Incoloy 800, 800H, and 800HT alloy is used for applications involving high temperature conditions which can include furnaces, catalytic reactors, and gas turbines, because of their resistance to oxidation, carburization, and resistance to thermal cycling. These materials are also implemented in the construction of nuclear power generation systems, waste incineration systems, and other high-stress applications that require significantly long material lifetimes.
