Devang Fittings is a leading Incoloy 825 Forged Fittings manufacturer and supplier, situated in Kolkata, India. We are renowned for our accuracy in engineering and adherence to excellence, with our forged elbows, tees, couplings, unions, and plugs made of Incoloy 825 to operate in highly corrosive and challenging conditions. Our forged fittings are made in line with global standards like ASTM B564 to deliver high dimensional accuracy and mechanical performance. Devang Fittings Incoloy 825 Forged Fittings find extensive applications in chemical processing, pollution control, marine, and oil & gas industries where corrosion resistance and strength are paramount.
| ASTM B564 Incoloy Alloy 825 Forged Fittings Specification | |
|---|---|
| Specifications | ASTM B564 / ASME SB564 |
| Standards | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8″ NB to 4″ NB (Socketweld & Screwed-Threaded) |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Type | Socket Weld (S/W) & SCREWED (SCRD) – NPT, BSP, BSPT |
| Gr.825 Incoloy Alloy Forged Pipe Fittings Chemical Composition | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Grade | Ni | C | Fe | Si | Mn | S | Al | Ti | Cu | Cr | Mb |
| Incoloy 825 | 38.0 – 46.0 | 0.05 max | 22.0 min | 0.5 max | 1.0 max | 0.03 max | 0.2 max | 0.6 – 1.2 | 1.5 – 3.0 | 19.5 – 23.5 | 2.5 – 3.5 |
| Incoloy 825 Forged Fittings Mechanical Properties | |||||
|---|---|---|---|---|---|
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000, MPa -550 | Psi – 32,000, MPa – 220 | 30 % |
| Incoloy ASTM B564 Forged Fittings Equivalent Grades | ||||||||
|---|---|---|---|---|---|---|---|---|
| STANDARD | UNS | WNR NO. | AFNOR | EN | JIS | BS | GOST | OR |
| Incoloy 825 | N08825 | 2.4858 | NFE30C20DUM | NiCr21Mo | NCF 825 | NA 16 | ЭП703 | XH38BT |
Incoloy 825 is an alloy of nickel-iron-chromium with molybdenum, copper, and titanium additions that possess superior resistance to corrosive environments of a broad spectrum. It has approximately 38–46% nickel, 19.5–23.5% chromium, 2.5–3.5% molybdenum, 1.5–3% copper, and titanium as stabilizer. These fittings offer tensile strength around 585 MPa, yield strength of 220 MPa, and elongation of 30–40%. Incoloy 825 retains mechanical strength in both oxidizing and reducing conditions and resists pitting, crevice corrosion, stress corrosion cracking, and attack from acid—particularly from sulfuric and phosphoric acids.
Devang Fittings is a leading supplier of Incoloy 825 Forged Fittings in Kolkata, India. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Incoloy 825 Forged Fittings from Devang Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Yes, custom sizes for Incoloy 825 Forged Fittings are available at Devang Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@devangfittings.co.in
Incoloy 825 Forged Fittings find extensive applications in harsh conditions where good resistance to corrosion is required. Typical uses are chemical plant piping, acid manufacturing plants, nuclear fuel processing, marine exhaust manifolding, and offshore oil and gas platforms. They are suitable for heat exchangers, condensers, and evaporators under seawater and severe chemical exposure. With their high resistance to chloride-related corrosion and acidic conditions, they prevent equipment deterioration, lower maintenance, and provide safe operation withstanding high temperatures and pressures. Their versatility and toughness make them a first choice for critical service use.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
