Devang Fittings, Kolkata, India, is a well-known Inconel 601 Forged Fittings manufacturer and supplier with excellent performance and longevity in harsh service conditions. Withstanding corrosive conditions and high temperatures, these fittings are extensively used in petrochemical, power generation, thermal processing, and aerospace industries. Devang Fittings offers a full range of forged fittings—elbows, tees, couplings, and unions—forged to international standards and specifications. Devang concentrates on precision engineering, corrosion resistance, and extended service life to ensure that every Inconel 601 forged fitting provides maximum reliability in high-pressure piping systems.
| Form | : | Tee, Union, Full Coupling, Half Coupling,Elbow 45 Deg & 90 Deg, Swage Nipple, Cross, Cap, Plug Bush |
| Size | : | ⅛” to 4” |
| Grade | : | Inconel 601 (UNS No. N06601) |
| Standard | : | ASTM / ASME SB 167 / ASTM / ASME SB 564 / 160 / 472 |
| Dimensions | : | ANSI/ASME B16.11 & BS3799, etc. |
| Class | : | 2000LBS, 3000LBS, 6000LBS, 9000LBS, etc. |
| Type | : | Socket Weld (S/W) & SCREWED (SCRD) – NPT, BSP, BSPT, Threaded Fittings |
Inconel 601 is an aluminum-backed nickel-chromium alloy with high oxidation and corrosion resistance at elevated temperatures. The standard composition contains approximately 58% nickel, 21–25% chromium, and minor amounts of aluminum and iron. These forged fittings retain their strength at temperatures up to 1150°C and have a tensile strength of about 585 MPa. Inconel 601 also shows great resistance to creep and metallurgical stability as well as weldability and mechanical strength on thermal cycling and stress.
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 601 | 0.10 max | 1.00 max | 0.50 max | 0.015 max | 1.0 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.1 g/cm3 | 1411 °C (2571 °F) | 550 MPa, 80000 psi | 205 MPa, 30000 psi | 30 % |
Devang Fittings is a leading supplier of Inconel 601 Forged Fittings in Kolkata, India. We offer an extensive range of Inconel 601 Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 601 | 2.4851 | N06601 | NCF 601 | NA 49 | XH60BT | NC23FeA | NiCr23Fe |
Choose Inconel 601 Forged Fittings from Devang Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Yes, custom sizes for Inconel 601 Forged Fittings are available at Devang Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@devangfittings.co.in
Inconel 601 Forged Fittings find applications in heat exchangers, furnace components, gas turbine parts, chemical processing facilities, and nuclear reactor systems. Due to their superior resistance to scaling, oxidation, and carburization at high temperatures, they suit high-pressure and high-stress applications. They are manufactured in socket weld and threaded configurations and come in different sizes and pressure classes from Devang Fittings, ensuring reliable, leak-free connections for challenging industrial environments.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
