Devang Fittings, a reliable manufacturer and supplier located in Kolkata, India, has been providing high-quality pipe fittings for a variety of industrial applications. Our fittings are known for their accuracy and toughness; and we have a variety of materials, with Inconel pipe fittings being the most heat and corrosion-resistant. Inconel fittings are made to withstand extreme conditions; and are often utilized in the aerospace, chemical processing, and power industries. Devang Fittings is your trusted manufacturer to quality and creative industrial solutions.
| Specification | ASTM B366, ASTM SB 366, ASTM B564, ASME SB564 |
| Grade | Inconel 600 (UNS N06600, Alloy 600, 2.4816), Inconel 601 (UNS N06601, Alloy 601, 2.4851), Inconel 625 (UNS N06625, Alloy 625, 2.4856), Inconel 800 (UNS N08800, Alloy 800) |
| Type | Seamless / Welded / Fabricated |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Range | ½”NB to 24″NB in Sch 10s, 40s, 80s, 160s, XXS. |
| Dimensions | ANSI/ASME B16.9, B16.28, MSS-SP-43. |
Inconel pipe fittings are made from a nickel-chromium alloy that is sometimes supplemented with other elements (such as molybdenum, iron, cobalt, and niobium) to enhance their performance. The composition makes it resistant to oxidation and corrosion and can withstand high temperature environments. Inconel fittings also have strong mechanical characteristics with tensile strengths ranging from 550 to 1200 MPa and yield strength. Inconel fittings are also tough and stable at high temperature (they are good at up to 980°C or 1800°F). It is this unique value to the petroleum, aerospace, marine, and petrochemical industries and its demanding applications that has made Inconel fittings worth consideration.
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Inconel 601 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Inconel 718 | 0.08 max | 0.35 max | 0.35 max | 0.015 max | 0.30 max | – | 50.00 – 55.00 | 17.00 – 21.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
Devang Fittings is a leading supplier of Inconel Pipe Fittings in Kolkata, India. We offer an extensive range of fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WNR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 600 | 2.4816 | N06600 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
| Inconel 601 | 2.4851 | N06601 | NCF 601 | NA 49 | XH60BT | NC23FeA | NiCr23Fe |
| Inconel 625 | 2.4856 | N06625 | NCF 625 | NA 21 | ХН75МБТЮ | NC22DNB4M | NiCr22Mo9Nb |
| Inconel 718 | 2.4668 | N07718 | – | – | – | – | – |
Inconel Pipe Fittings from Devang Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
| NOMINAL PIPE SIZE | ALL FITTINGS | ALL FITTINGS | 180 DEG RETURN BENDS | REDUCERS | ELBOWS AND TEES | 180 DEG RETURN BENDS | CAPS |
|---|---|---|---|---|---|---|---|
| NPS | ID at End (1), (3), (4) | OD at Bevel (1), (2) | Centre-to- Centre O | Overall Length H | Centre -to- End Dimension A, B, C, M | Alignment of Ends U | Overall Length E |
| ½ to 2½ | 0.003 | 0.006 -0.003 | 0.025 | 0.006 | 0.006 | 0.003 | 0.012 |
| 3 to 3 ½ | 0.006 | 0.006 | 0.025 | 0.006 | 0.006 | 0.003 | 0.012 |
| 4 | 0.006 | 0.006 | 0.025 | 0.006 | 0.006 | 0.003 | 0.012 |
| 5 to 8 | 0.006 | 0.009 -0.006 | 0.025 | 0.006 | 0.006 | 0.003 | 0.025 |
| 10 to 18 | 0.012 | 0.016 -0.012 | 0.038 | 0.009 | 0.009 | 0.006 | 0.025 |
| 20 to 24 | 0.019 | 0.025 -0.019 | 0.038 | 0.009 | 0.009 | 0.006 | 0.025 |
| 26 to 30 | 0.019 | 0.025 -0.019 | … | 0.019 | 0.012 | … | 0.038 |
| 32 to 48 | 0.019 | 0.025 -0.019 | … | 0.019 | 0.019 | … |
Inconel pipe fittings have many benefits, and are perfect for severe environments. These fittings are known for their extreme temperature resistance, oxidation resistance and corrosion resistance, making them stable in extreme environments. They will remain stable and mechanically strong over a broad range of temperature fluctuations, minimizing the potential for deformation or failure. Inconel is known for standing up in a high-pressure environment, which is why these fittings are often used in aerospace, chemical processing, and power plants applications, industries where critical applications are common. Inconel fittings have good resistance to cracking due to mechanical and thermal stress, which promotes peace of mind, and longevity. They have a low maintenance outlay that, when factored over the duration of their use, can be considered cost-effective.
Nominal Pipe Size | 45° Elbow | 90° Elbow | OD | 180° Returns | ||||
(inch.) | LR | SR | LR | LR | ||||
Radius (inch.) | Center to Face (inch.) | Center to Face (inch.0) | Center to Face (inch.0) | (inch) | (millimeter) | Back to face (inch.) | Center to Center (inch.) | |
1/2 | 5/8 | – | 1 1/2 | 0.0840 | 21.03 | 1 7/8 | 2 | |
3/4 | 7/16 | – | 1 1/8 | 1.0050 | 26.07 | 1 11/16 | 2 1/4 | |
1 | 7/8 | 1 | 1 1/2 | 1.0315 | 33.04 | 2 3/16 | 3 | |
1 1/4 | 1 | 1 1/4 | 1 7/8 | 1.0660 | 42.02 | 2 3/4 | 3 3/4 | |
1 1/2 | 3 | 1 1/8 | 1 1/2 | 2 1/4 | 1.0900 | 48.03 | 3 1/4 | 4 1/2 |
2 | 4 | 1 3/8 | 2 | 3 | 2.0375 | 60.03 | 4 3/16 | 6 |
2 1/2 | 5 | 1 3/4 | 2 1/2 | 3 3/4 | 2.0875 | 73.00 | 5 3/16 | 7 1/2 |
3 | 6 | 2 | 3 | 4 1/2 | 3.0500 | 88.09 | 6 1/4 | 9 |
3 1/2 | 7 | 2 1/4 | 3 1/2 | 5 1/4 | 4.0000 | 101.06 | 7 1/4 | 10 1/2 |
4 | 8 | 2 1/2 | 4 | 6 | 4.0500 | 114.03 | 8 1/4 | 12 |
5 | 10 | 3 1/8 | 5 | 7 1/2 | 5.0563 | 141.03 | 10 5/16 | 15 |
6 | 12 | 3 3/4 | 6 | 9 | 6.0625 | 168.03 | 12 5/16 | 18 |
8 | 12 | 5 | 8 | 12 | 8.0625 | 219.01 | 16 5/16 | 24 |
10 | 15 | 6 1/4 | 10 | 15 | 10.0750 | 273.01 | 20 3/8 | 30 |
12 | 18 | 7 1/2 | 12 | 18 | 12.0750 | 323.09 | 24 3/8 | 36 |
Yes, custom sizes for Inconel Pipe Fittings are available at Devang Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@devangfittings.co.in.
Inconel pipe fittings are adapted to numerous industries needing extreme durability and extreme condition resistance. In the aerospace industry, Inconel fittings are critical for jet engine and exhaust systems due to their ability to withstand extreme heat and resistant to corrosion. In the oil and gas and petrochemical industries, Inconel fittings are used to transport fluids with high-pressure and corrosive region characteristics. In the power generation industry, heating/cooling systems often use inconel inlet/outlet fittings to handle steam turbines (of both types) and heat exchangers. The marine industry also frequently employs Inconel fittings due to the extreme corrosion properties necessary for seawater. Inconel fittings allow you to have reliability in very disruptive industries and environments.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
