Devang Fittings is a leader in manufacturing and supplying fittings and fittings accessories in Kolkata, India, and delivering high quality fittings and accessories to various industries. Devang Fittings is committed to precision engineering, innovation, and customer satisfaction. We provide a wide range of products that meet the rigorous needs of a variety of applications. Their Nickel Alloy 200 Forged Fittings are highly regarded for their high-strength and resistance to corrosion; keeping the products durable in difficult conditions within industries like chemical processing, power generation and aerospace, and to withstand long service.
| ASTM B564 – ASME SB564 | Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings |
| ASME B16.9 | Factory-Made Wrought Buttwelding Fittings |
| ASME B16.11 | Socket Welding and Threaded Forged Fittings |
| MSS SP-43 | Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications |
| MSS SP-95 | Swage(d) Nipples and Bull Plugs |
| BS3799 | Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry |
Nickel Alloy 200 (UNS N02200) is an alloy with primarily nickel content, at nearly 99% purity, connected with small amounts of iron, copper and others. It possesses good corrosion resistance in alkaline and acidic conditions and it has good strength and ductility at normal to elevated temperatures. The mechanical properties are tensile strength is 70-90 ksi, yield strength is 30-50 ksi, and elongation is approximately 35-50%. Due to its corrosion resistance to oxidation and perilous thermal conductivity; Nickel Alloy 200 has usage in the chemical processing industry or electronics.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
|---|---|---|---|---|---|---|---|
| Nickel 200 | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Nickel 200 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
Devang Fittings is a leading supplier of Nickel Alloy 200 Forged Fittings in Kolkata, India. We offer an extensive range of Nickel Alloy 200 Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Density (Kg.m-1) | 84.3 |
|---|---|
| Magnetic Permeability (20°C) | <1.005 |
| Curie Temperature (°C) | -90 |
| Young’s Modulus (N/mm2) | 179 x 103 |
| Specific Heat, 20°C (J.Kg-1.°K-1) | 418 |
| Specific Electrical Resistance, 20°C (?O.m) | 0.62 |
| Thermal conductivity,20°C (W.m-1.°K-1) | 17.5 |
| Mean coefficient of thermal expansion, 20-100°C (°K-1) | 13.4 x 10-6 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 200 | 2.4066 | N02200 | NW 2200 | NA 11 | НП-2 | N-100M | Ni 99.2 |
Nickel Alloy 200 Forged Fittings from Devang Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Nickel Alloy 200 Forged Fittings have remarkable benefits, which include outstanding corrosion resistance; especially in alkaline and gently acidic environments, ideal for chemical processing and marine uses. They are durable and have long service life due to their strength, mechanical properties, and weldability. Nickel Alloy 200 is resistant to stress corrosion cracking and can perform in high temperatures making it appropriate for demanding applications. Nickel Alloy 200 also has many characteristics of good thermal and electrical conductivity that enhances its performance in electrical systems and heat exchangers ensuring reliability and longevity even in harsh conditions.
Yes, custom sizes for Nickel Alloy 200 Forged Fittings are available at Devang Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@devangfittings.co.in.
Nickel Alloy 200 Forged Fittings see a wide range of application in areas where durability and corrosion resistance are critical. They’re an excellent choice for corrosive elements and environments, including chemicals of both an acidic and alkaline nature like the chemical processing industries. It should also be noted that Nickel Alloy 200 Forged Fittings are used consistently in food processing, petrochemical, and pharmaceutical industries, as well as in marine and power production applications. Their versatility is only matched by their amazing weldability and resistance to oxidation. Nickel Alloy 200 Forged Fittings can be found in heat exchangers, pumps, valves, and cryogenic applications. Regardless of their toughness, they should be included in applications that might entail demanding, high strength performance requirements.
