Stainless Steel 17-4 PH Pipe Fittings are strong, corrosion-resistant parts designed for high-performance applications needing superior mechanical properties coupled with corrosion resistance to some extent. These precipitation-hardened fittings produced by trusted suppliers like Devang Fittings in Kolkata, India, are extensively utilized in the aerospace, chemical process, marine, and power generation industries because of their superior hardness, strength, and dimensional stability even in corrosive or high-stress environments.
| Specification | ASTM A403 / ASME SA403 |
| Standard | EN, ISO, DIN, JIS, NPT |
| Dimension Standard | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| Size | 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated) |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Type | Seamless / Welded / Fabricated |
| Pressure-Temperature Class | 150LB, 300LB, 600LB, 1500LB, 2500LB. |
| Schedule | Schedule 5 TO Schedule XXS. |
| Type Of Dimension | BS1640, EN 10253 – 4, DIN 2605, JIS B2312, ANSI B16.9, MSS SP-75, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS B2313 |
17-4 PH (precipitation hardening) stainless steel has around 15–17.5% chromium, 3–5% nickel, 3–5% copper, and a trace of niobium (columbium), which increases the precipitation-hardening ability of the alloy. In heat-treated (usually H900–H1150 condition) form, it provides tensile strengths between 930 MPa and more than 1310 MPa and yield strengths between 725 MPa and more than 1170 MPa, with good toughness and moderate corrosion resistance similar to that of type 304 stainless steel.
| Grade | C | Cb+Ta | Cr | Cu | Fe | Mn | Ni | P | S | Si |
| SS 17-4 PH | 0.07 max | 0.15-0.45 | 15.00-17.50 | 3.00-5.00 | Bal | 1.0 max | 3.0-5.0 | 0.40 max | 0.03 max | 1.0 max |
| Grade | Tensile Strength ksi (MPa) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Rockwell) MAX |
| SS 17-4 PH | 170000 psi | 140000 psi | 6% | 38 |
Devang Fittings one of the largest suppliers of Stainless Steel 17-4 PH Pipe Fittings in Kolkata, India. We specialize in providing a wide range of high-quality, durable fittings for various industrial applications. Our inventory includes elbows, tees, reducers, couplings, and other essential fittings designed to offer exceptional corrosion resistance and strength. Stainless Steel 17-4 PH is known for its cost-effectiveness and excellent mechanical properties, making it ideal for industries such as construction, chemical processing, and food processing. With a commitment to customer satisfaction, timely delivery, and competitive pricing, we are the trusted choice for Stainless Steel 17-4 PH Pipe Fittings in the India.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless Steel 17-4 PH Pipe Fittings from Devang Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Yes, custom sizes are available for Stainless Steel 17-4 PH Pipe Fittings to meet specific requirements. We offer tailored solutions to ensure precise fit and performance for various applications. For more information, please contact us at sales@devangfittings.co.in.
| STANDARD | WERKSTOFF NR. | UNS |
| SS 17-4 PH | 1.4542 | S17400 |
Stainless Steel 17-4 PH Pipe Fittings find widespread applications in high-performance applications like pressure vessels, aerospace fittings, pump shafts, casks for nuclear waste, and valve components. These can withstand mechanical and thermal stress and still retain strength and dimensional stability, thus finding their application in places with low distortion requirements, high fatigue life, and less maintenance. These fittings provide long-lasting reliability and high performance in mildly corrosive and heavy-load service conditions.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
