Stainless Steel 304/304L Forged Fittings are incredibly versatile and resistant to corrosion, making them a go-to choice in various industrial piping systems. Their impressive strength, durability, and ease of fabrication are just a few reasons why they’re so popular. Trusted suppliers like Devang Fittings in Kolkata, India, manufacture these fittings, which are perfect for applications that demand robust mechanical properties, high resistance to corrosion, and excellent weldability. The 304L variant, with its lower carbon content, significantly reduces the risk of carbide precipitation during welding, making it especially suitable for high-purity or welded systems.
Specifications : ASTM A182 & ASME SA182
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
Grade 304/304L stainless steel is an austenitic alloy that typically contains around 18–20% chromium and 8–12% nickel. The 304L version has a maximum carbon content of 0.03%, compared to 0.08% in 304, which enhances its resistance to intergranular corrosion after welding. These alloys boast tensile strengths of about 485 MPa and yield strengths close to 170 MPa, all while maintaining excellent ductility, toughness, and corrosion resistance across various environments, including both oxidizing and mildly reducing conditions.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 | – |
| SS 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 13 | – |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Devang Fittings is a leading supplier of Stainless Steel 304/304L Forged Fittings in Kolkata, India. We offer an extensive range of Stainless Steel 304/304L Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 304 | 1.4301 | S30400 | SUS 304 | 304S31 | 08Х18Н10 | Z7CN18‐09 | X5CrNi18-10 |
| SS 304L | 1.4306/1.4307 | S30403 | SUS 304L | – | 03Х18Н11 | Z3CN18‐10 | X2CrNi18-9 / X2CrNi19-11 |
| Products | Size | |
|---|---|---|
| ASTM A182 SS 304 Forged 90° Elbow | ASTM A182 SS 304 Forged 45° Elbow | Sizes 1/8″– 4″ Pressure Ratings – 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| ASTM A182 SS 304 Forged Tee | ASTM A182 SS 304 Forged Union | |
| ASTM A182 SS 304 Forged Cross | ASTM A182 SS 304 Forged Insert | |
| ASTM A182 SS 304 Forged Bushing | ASTM A182 SS 304 Forged Pipe Nipple | |
| ASTM A182 SS 304 Forged Cap | ASTM A182 SS 304 Forged Coupling | |
| ASTM A182 SS 304 Forged Plug | ASTM A182 SS 304 Forged Street Elbow | |
Choose Stainless Steel 304/304L Forged Fittings from Devang Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Yes, custom sizes for Stainless Steel 304/304L Forged Fittings are available at Devang Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@devangfittings.co.in
| DN-NPT | MAJOR DIAMETER MM | TAPPING DRILL SIZE MM | TPI | PITCH MM |
|---|---|---|---|---|
| 1/16″ | 7.895 | 6.00 | 27 | 0.941 |
| 1/8″ | 10.242 | 8.25 | 27 | 0.941 |
| 1/4″ | 13.616 | 10.70 | 18 | 1.411 |
| 3/8″ | 17.055 | 14.10 | 18 | 1.411 |
| 1/2″ | 21.223 | 17.40 | 14 | 1.814 |
| 3/4″ | 26.568 | 22.60 | 14 | 1.814 |
| 1″ | 33.228 | 28.50 | 11.5 | 2.209 |
| 1¼” | 41.985 | 37.00 | 11.5 | 2.209 |
| 1½” | 48.054 | 43.50 | 11.5 | 2.209 |
| 2″ | 60.092 | 55.00 | 11.5 | 2.209 |
| 2½” | 72.699 | 65.50 | 8 | 3.175 |
| 3″ | 88.608 | 81.50 | 8 | 3.175 |
| 3½” | 101.316 | 94.30 | 8 | 3.175 |
| 4″ | 113.973 | 107.00 | 8 | 3.175 |
| 5″ | 141.300 | 134.384 | 8 | 3.175 |
| 6″ | 168.275 | 161.191 | 8 | 3.175 |
| 8″ | 219.075 | 211.673 | 8 | 3.175 |
| 10″ | 273.050 | 265.311 | 8 | 3.175 |
| 12″ | 323.850 | 315.793 | 8 | 3.175 |
| Description | Class Designation | ||
|---|---|---|---|
| 3000 | 6000 | 9000 | |
| Elbows 45 and 90 degrees, Tees, Crosses, Couplings, Half-Couplings, End or Pipe Caps | 1/2 – 4 | 1/2 – 2 | 1/2 – 2 |
| 1/2 – 4 | 1/2 – 2 | 1/2 – 2 | |
| 1/2 – 4 | 1/2 – 2 | 1/2 – 2 | |
| Pipe Size by Wall Thickness | SCH 80 / XS | SCH 160 | XXS |
You’ll find Stainless Steel 304/304L Forged Fittings in a wide range of industries, from food and beverage processing to pharmaceuticals, petrochemicals, water treatment, and oil and gas. They’re commonly used for high-pressure pipe connections, instrumentation systems, and steam lines. Thanks to their outstanding resistance to corrosion and mechanical stress, these forged fittings deliver long-lasting performance and reliability, whether in corrosive or sanitary environments.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
