Stainless Steel 304H Pipe Fittings are high-strength, heat-resisting parts designed for applications demanding superior performance under high temperature conditions. Produced by trusted providers like Devang Fittings in Kolkata, India, these fittings are the high-carbon version of the standard 304 grade, providing superior creep resistance and strength in high-temperature conditions. Their strong build and superior weldability make them suitable for critical pressure systems and thermal processing equipment.
Specifications : ASTM A403 / ASME SA403
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Size : 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated)
Type : Seamless / Welded / Fabricated
Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Thickness : Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS
304H stainless steel is an austenitic stainless steel alloy containing around 18–20% chromium and 8–11% nickel, with higher carbon content (0.04–0.10%) than the regular 304. This added carbon enhances strength and creep resistance at temperatures greater than 500°C. It has a tensile strength of around 585 MPa and a yield strength of around 240 MPa with high oxidation resistance and structural stability when subjected to thermal stress.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 304H | 0.10 max | 2.0 max | 0.75 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 10.5 | – |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
Devang Fittings is a leading manufacturer and supplier of premium pipe fittings based in Kolkata, India. Known for its unique and innovative products, Braxton specializes in providing reliable solutions to suit a variety of industrial applications. Among their offerings, stainless steel 304H pipe fittings stand out for their durability, superior heat resistance and corrosion resistance, making them ideal for harsh environments With a commitment to excellence Braxton ensures that top notch products and unmatched customer service around the world.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless Steel 304H Pipe Fittings from Devang Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
| STANDARD | WERKSTOFF NR. | UNS |
| SS 304H | 1.4301 | S30409 |
| Physical Properties | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Electrical Resistivity (n.m) | Thermal Conductivity (W/m.K) | Mean Coefficient of Thermal Expansion (m/m/0C) | Specific Heat 0-1000C (J/kg.K) | |||
| at 1000C | at 5000C | 0-1000C | 0-3150C | 0-5380C | |||||
| 304H | 8000 | 193 | 720 | 16.2 | 21.5 | 17.2 | 17.8 | 18.4 | 500 |
Yes, custom sizes are available for Stainless Steel 304H Pipe Fittings to meet specific requirements. We offer tailored solutions to ensure precise fit and performance for various applications. For more information, please contact us at sales@devangfittings.co.in.
Stainless Steel 304H Pipe Fittings are widely applied in power generation plants, refineries, boilers, heat exchangers, superheaters, and other high-temperature, high-pressure processes. Their strength retention and resistance to scaling and corrosion when subjected to extended exposure to heat makes them ideal for high-demand industrial processes. The fittings provide a dependable, long-life solution for applications where thermal efficiency, mechanical strength, and corrosion resistance are critical.
