Stainless Steel 316/316L Forged Fittings Manufacturer and Supplier in Kolkata, India

Devang Fittings, a Kolkata-based India company, is a trusted producer and provider of Stainless Steel 316/316L Forged Fittings with corrosion-resistant and high-strength applications for critical piping systems. Precision manufactured with excellent raw materials, our forged fittings are constructed to withstand rigorous and corrosive applications like marine, chemical, and pharmaceutical industries. Stainless Steel 316/316L offers superior resistance against pitting, crevice corrosion, and oxidation. Devang Fittings confirms that every product is of high quality, producing forged fittings that are long-lasting, dimensionally accurate, and perform well even in high and low-temperature service conditions.

Stainless Steel 316 Threaded Fitting Price List in Kolkata, UNS S31600 Stainless Steel Forged Fittings Supplier in India, Stainless Steel 316L High Pressure Forged Fittings Exporter in Kolkata, Stainless Steel 316 Hex Plug Supplier in Kolkata, SS 316 Threaded Pipe Elbow Exporter in Kolkata, SS UNS S31603 Pipe Nipple Size Chart, Stainless Steel 316L Forged Fittings Price in India, SS 316 Screwed Fittings in Kolkata, Stainless Steel 1.4404 Forged Fittings Supplier in Kolkata, Stainless Steel 316L Hexagonal Plug Stockist in India, Stainless Steel 316L Forged Fittings Exporter in India

Stainless Steel 316/316L Forged Fittings Specification

Specification	ASTM A182 / ASME SA182
Dimension Standard	ASME B16.11, MSS-SP-79, MSS-SP-83, MSS-SP-95, MSS-SP-97, BS3799
Size	1/8″ NB to 4″ NB
Type	Socketweld Fittings, Screwed-Threaded Fittings
Pressure-Temperature Class	Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS.

Stainless Steel 316/316L is an austenitic stainless steel with chromium (16–18%), nickel (10–14%), and molybdenum (2–3%) added to it, increasing resistance against chloride-induced corrosion. The 316L grade contains less carbon, making weldability greater and intergranular corrosion lower. These alloys yield about 515 MPa tensile strength, 205 MPa yield strength, and elongation of 35%. They are both non-magnetic when in the annealed state and possess strength and corrosion resistance at a broad range of temperatures, thus well suited for applications in harsh and aggressive conditions.

Stainless Steel 316/316L Forged Fittings Chemical Compostion

Grade	C	Mn	Si	P	S	Cr	Mo	Ni	Fe
SS 316	0.08 max	2.0 max	1.0 max	0.045 max	0.030 max	16.00 – 18.00	2.00 – 3.00	11.00 – 14.00	67.845 min
SS 316L	0.035 max	2.0 max	1.0 max	0.045 max	0.030 max	16.00 – 18.00	2.00 – 3.00	10.00 – 14.00	68.89 min

Stainless Steel 316/316L Forged Fittings Mechanical Properties

Grade	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
SS 316	8.0 g/cm3	1400 °C (2550 °F)	Psi – 75000 , MPa – 515	Psi – 30000 , MPa – 205	35 %
SS 316L	8.0 g/cm3	1399 °C (2550 °F)	Psi – 75000 , MPa – 515	Psi – 30000 , MPa – 205	35 %

SS 316 Socket Weld Fittings Exporter in India, DIN 1.4401 Stainless Steel Union Price List in Kolkata, Stainless Steel 316 Forged Fittings Supplier in India, ANSI B16.11 Stainless Steel 316L Forged Fittings Exporter in Kolkata, Stainless Steel 316 Forged Elbow Exporter in Kolkata, Stainless Steel 316 Forged Tee in India, SS 316 Socket Weld Fittings Size Chart, Stainless Steel 316 Coupling Price in India, UNS S31600 Stainless Steel Forged Threaded 90 deg. Elbow Weight Chart, Stainless Steel 316L Stainless Steel Cross Trader Supplier in Kolkata, Stainless Steel 316 Socket weld Fittings Stockist in India

Largest Stainless Steel 316/316L Forged Fittings Supplier in Kolkata, India

Devang Fittings is a leading supplier of Stainless Steel 316/316L Forged Fittings in Kolkata, India. We offer an extensive range of Stainless Steel 316/316L Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Stainless Steel 316/316L Forged Fittings Equivalent Grade

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
SS 316	1.4401 / 1.4436	S31600	SUS 316	316S31 / 316S33	–	Z7CND17‐11‐02	X5CrNiMo17-12-2 / X3CrNiMo17-13-3
SS 316L	1.4404 / 1.4435	S31603	SUS 316L	316S11 / 316S13	03Ch17N14M3 / 03Ch17N14M2	Z3CND17‐11‐02 / Z3CND18‐14‐03	X2CrNiMo17-12-2 / X2CrNiMo18-14-3

Why Choose Stainless Steel 316/316L Forged Fittings from Devang Fittings?

Choose Stainless Steel 316/316L Forged Fittings from Devang Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.

Stainless Steel UNS S31603 Full Coupling Exporter in India, SS 316 Forged Socket weld Fittings Sizes in mm, Stainless Steel 316 Forged Fittings Manufacturer in Kolkata, Stainless Steel DIN 1.4404 Threaded Fittings Supplier in Kolkata, ASME SA182 Stainless Steel 316L Forged Fittings Price List in Kolkata, SUS 316 Forged Union Distributor in Kolkata, SS UNS S31603 Forged Fittings Supplier in Kolkata, Stainless Steel 316 Forged Cap Distributor in India

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Types of Stainless Steel 316/316L Forged Fittings

Are Custom Sizes Available for Stainless Steel 316/316L Forged Fittings?

Yes, custom sizes for Stainless Steel 316/316L Forged Fittings are available at Devang Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@devangfittings.co.in

Dimensions of SS 316/316L Forged Fittings

ASME b16.9 Fittings Normal Pipe Size		ANSI b16 9 Pipe Fitting O D Y	Wall Thickness T (Pipe Elbow Sch.)		LR 45 Deg Elbows Centre to Face B	SR 45 Deg Elbows Weight	LR 90 Deg Elbows Centre to Face A	LR 90 Deg Elbows Weight In Below	SR 90 Deg Elbows Centre to Face A	SR 90 Deg Elbows Weight In Below
mm	inch	mm	mm	Schedule	mm	kg	mm	kg	mm	kg
15	1/2”	21.3	2.78	STD	15.9	0.04	38.1	0.08	–	–
			3.73	X.S	15.9	0.05	38.1	0.10	–	–
20	3/4”	26.7	2.87	STD	11.1	0.04	28.6	0.08	–	–
			3.91	X.S	11.1	0.05	28.6	0.11	–	–
25	1”	33.4	3.38	STD	22.2	0.09	38.1	0.15	25.4	0.11
			4.55	X.S	22.2	0.11	38.1	0.19	25.4	0.14
32	11/4”	42.2	3.56	STD	25.4	0.14	47.6	0.28	31.75	0.18
			4.85	X.S	25.4	0.2	47.6	0.39	31.75	0.24
40	11/2”	48.3	3.68	STD	28.6	0.2	57.1	0.4	38.1	0.26
			5.08	X.S	28.6	0.25	57.1	0.5	38.1	0.35
50	2”	60.3	3.91	STD	34.9	0.36	76.2	0.72	50.8	0.5
			5.54	X.S	34.9	0.5	76.2	1.0	50.8	0.68
65	21/2”	73.0	5.16	STD	44.4	0.73	95.2	1.46	63.5	0.95
			7.01	X.S	44.4	0.91	95.2	1.82	63.5	1.27
80	3”	88.9	5.49	STD	50.8	1.1	114.3	2.18	76.2	1.45
			7.62	X.S	50.8	1.45	114.3	2.86	76.2	1.95
100	4”	114.3	6.02	STD	63.5	2.1	152.4	4.2	101.6	2.8
			8.56	X.S	63.5	2.9	152.4	5.7	101.6	3.9
125	5”	141.3	6.65	STD	79.4	3.4	190.0	6.8	127.0	4.8
			9.5	X.S	79.4	5.0	190.0	10.0	127.0	6.5
150	6”	168.3	7.11	STD	95.2	5.1	229.0	10.1	152.4	6.8
			10.97	X.S	95.2	7.7	229.0	15.3	152.4	10.2
200	8”	219.1	8.18	STD	127.0	10.2	305.0	20.4	203.0	13.6
			12.7	X.S	127.0	15.5	305.0	30.9	203.0	20.9
250	10”	273.9	9.27	STD	159.0	18.1	381.0	36.1	254.0	24.1
			12.7	X.S	159.0	24.4	381.0	48.8	254.0	32.5
300	12”	323.9	9.52	STD	190.0	26.6	457.0	53.1	305.0	35.4
			12.7	X.S	190.0	35.0	457.0	70.0	305.0	46.7
350	14”	355.6	9.52	STD	222.0	34.1	533.0	68.1	356.0	45.4
			12.7	X.S	222.0	45.0	533.0	90.0	356.0	60.0
400	16”	406.4	9.52	STD	254.0	45.0	610.0	89.3	406.0	59.5
			12.7	X.S	254.0	59.0	610.0	118.0	406.0	78.7
450	18”	457.0	9.52	STD	286.0	56.5	686.0	113.0	457.0	75.6
			12.7	X.S	286.0	75.0	686.0	150.0	457.0	100.0
500	20”	508.0	9.52	STD	318.0	85.0	762.0	140.0	508.0	93.5
			12.7	X.S	318.0	112.5	762.0	186.0	508.0	124.0
600	24”	610.00	9.52	STD	381.0	101.5	914.0	203.0	610.0	135.0
			12.7	X.S	381.0	134.5	914.0	269.0	610.0	179.0

Size of SS 316/316L Forged Fittings

NPS (inch)	Pipe Schedule.	OD (inch)	Wall Thick. (in)	Temperature
				100 Fitting	200 Fitting	300 Fitting	400 Fitting	500 Fitting
				Allowable Stress
				16700	16700	16700	15500	14400
1″	40	1.315	0.133	2205	2205	2205	2047	1902
	80	1.315	0.179	3061	3061	3061	2841	2640
	160	1.315	0.250	4493	4493	4493	4170	3874
1 1/2″	40	1.900	0.145	1629	1629	1629	1512	1404
	80	1.900	0.200	2303	2303	2303	2138	1986
	160	1.900	0.281	3362	3362	3362	3120	2899
2″	40	2.375	0.154	1371	1371	1371	1272	1182
	80	2.375	0.218	1985	1985	1985	1843	1712
	160	2.375	0.344	3283	3283	3283	3047	2831
3″	40	3.500	0.216	1301	1301	1301	1208	1122
	80	3.500	0.300	1844	1844	1844	1712	1590
	160	3.500	0.438	2787	2787	2787	2587	2403
4″	40	4.500	0.237	1102	1102	1102	1023	950
	80	4.500	0.337	1596	1596	1596	1482	1377
	160	4.500	0.531	2611	2611	2611	2424	2552
5″	40	5.563	0.258	965	965	965	896	832
	80	5.563	0.375	1428	1428	1428	1325	1231
	160	5.563	0.625	2474	2474	2474	2296	2133
6″	40	6.625	0.280	877	877	877	814	756
	80	6.625	0.432	1379	1379	1379	1280	1189
	160	6.625	0.719	2382	2382	2382	2211	2054
8″	40	8.625	0.322	771	771	771	716	665
	80	8.625	0.500	1218	1218	1218	1131	1050
	160	8.625	0.906	2298	2298	2298	2133	1982
10″	40	10.750	0.365	699	699	699	649	603
	80	10.750	0.594	1159	1159	1159	1075	999
	160	10.750	1.125	2289	2289	2289	2124	1974

ASTM A182 SS 316 End Cap Supplier in Kolkata, Stainless Steel 316 Forged Pipe Fittings Weight Chart, Stainless Steel 316L Welding Boss Exporter in India, Stainless Steel 316 High Pressure Forged Fitting Manufacturer in Kolkata, WERKSTOFF NR. 1.4401 Threaded Cross Price List in Kolkata, Stainless Steel 316 Threaded Fittings Sizes in mm, Stainless Steel 316L Forged Fittings Distributor in Kolkata, Stainless Steel 316L 180 Deg. Street Elbow in India, Stainless Steel 316 Forged Tee Distributor in India.

Application Industry of Stainless Steel 316/316L Forged Fittings

Stainless Steel 316/316L Forged Fittings find extensive applications in various industries like petrochemical, pharmaceutical, food processing, marine, and wastewater treatment owing to their high corrosion resistance and mechanical strength. They are best suited for joining and controlling the flow of corrosive fluids, acids, and chlorides within pipelines. These fittings are particularly worthy when used in saltwater or chemical-aggressive environments. The grade 316L is the choice for welded applications because of its resistance to carbide precipitation. Their corrosion resistance, pressure tolerance, and toughness make 316/316L forged fittings a reliable choice for long-term, high-performance operations.
