Titanium Buttweld Fittings are premium fittings in demand for their superior strength-to-weight ratio, corrosion resistance, and biocompatibility. These buttweld fittings are produced by top-notch suppliers such as Devang Fittings from Kolkata, India, to connect pipes and provide a smooth flow in different critical systems. The fact that titanium can withstand high temperatures and chemical exposure makes these buttweld fittings the most sought-after across highly demanding sectors. Precision-engineered with state-of-the-art techniques, Titanium Buttweld Fittings provide leak-tight, high-integrity joints and extended service life, even in the most corrosive and high-pressure applications.
Specifications : ASTM B363 / ASME SB363
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Size : 1/2″ to 24″ NB to 24″NB in
Type : Seamless / Welded / Fabricated
Schedule : SCH 10, SCH20, SCh20, SCh30
Grades : Titanium Gr. 1, Titanium Gr. 2, Titanium Gr. 4, Titanium Gr. 5, Titanium Gr. 7
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Ti Grade5 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| Titanium Gr. 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
Titanium Buttweld Fittings consist mainly of commercially pure titanium or titanium alloys like Grade 2 and Grade 5 (Ti-6Al-4V). These give superior corrosion resistance, particularly to seawater, chlorides, and acidic media. Titanium has a tensile strength from 350 MPa up to more than 1000 MPa, depending on grade, and high ductility and resistance to fatigue. Lightweight but high-performance structures are enabled by the low density of approximately 4.5 g/cm³. Titanium retains its mechanical properties both at cryogenic and high temperatures, and is therefore suitable for demanding conditions of service.
Devang Fittings is a leading supplier of Titanium Buttweld Fittings in Kolkata, India. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Titanium Buttweld Fittings from Devang Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
| Products | Size | |
| Titanium Elbow – Long Radius | Titanium Stub Ends | Sizes 1/2″ – 24″ |
| Titanium Elbow – Short Radius | Titanium Cross | |
| Titanium Reducing Elbow | Titanium Reducing Cross | |
| Titanium 45° Elbow | Titanium Tees | |
| Titanium Fabricated Tee | Titanium End Cap | |
| Titanium Reducer | Titanium Seamless Fittings | |
| Titanium Concentric Reducer | Titanium Pipe Nipple | |
| Titanium Eccentric Reducer | Titanium 5D Elbow | |
| Titanium 3D Elbow | Titanium Welded Pipe Fittings | |
Yes, custom sizes for Titanium Buttweld Fittings are available at Devang Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@devangfittings.co.in.
Titanium Buttweld Fittings have extensive application across industries demanding high performance in adverse conditions. In chemical processing, they deal with highly corrosive or reactive fluids. In aerospace and marine industries, their low weight and resistance to saltwater corrosion are particularly valuable. Power generation, particularly nuclear and geothermal, finds advantage in their heat and pressure resistance. In the medical and pharmaceutical industries, the biocompatibility of titanium provides fluid handling safety and long-term consistency. These are also applied in heat exchangers, desalination plants, and offshore drilling activities, where minimal maintenance and toughness are paramount for effective operations.
